Positive cold temperature for preservation of bodies at +4°C: temperature range -5°C to +10°C, 60 mm thick panels, 3 free-passage doors (H x W) 220 x 80 cm with 180° opening to left or right, all stainless steel 304 interior with 12 stretchers 60 cm wide.

Monobloc refrigeration unit, lateral rider mounting

Dimensions (W x H x D) 312 x 252 x 218cm (+30cm for wide unit)

Ref. 551283C All lacquered with PET55µ front Ref. 651283C 304 stainless steel front Ref. 751283C All stainless steel 30

Can be extended to 15 bodies by adding 3 stretchers and 3 KITRAIL, ceiling unit mandatory

Ref. 551583P All lacquered with PET55µ front panel Ref. 651583P All stainless steel 304 front panel Ref. 751583P All stainless steel 304 front panel

Negative-temperature cell variant -25°C to -0°C, panel thickness 100 mm

Dimensions (W x H x D) 220 x 260 x 230cm (+30cm for group width)

Ref. 551283N Fully lacquered with PET55µ front Ref. 651283N 304 stainless steel front Ref. 751283N 304 stainless steel front

AVAILABLE OPTIONS

Cladding Ref. 50000/PR Additional grey hard PVC cladding (ACROVYN) on door front.

Stretchers Choice of flat or curved stretchers, width 60cm, Ref. 1560 or Ref. 1561

With surcharge, Ref. 1571 curved stretcher width 75cm

Other free passages

62 cm wide

Width 100 cm incl. stretcher width 75cm

Group version Ceiling-mounted

Split system less than 15 m away

Packing: By unit on pallet
